Products

Power Supplies

Model Name
Standard Voltage
Voltage Range
Output Voltage
Battery
EMI Regulation
Permit Current of Charging Limit
Dimension
*

PS-1225-1

110/220VAC
85-265VAC
12VDC/1A
-
-
-
-
*

UP-608-6

110/220VAC
85-265VAC
5.5-8.1VDC
-
-
1850mA
-
*

PS-501-2

110/220VAC
85-265VAC
12VDC/1A&5VDC/4A
-
-
-
-
*

UP-604-2

110/220VAC
85-265VAC / 30Hz-70Hz
6VDC
Standard
Yes
2000 mA
157.5*122*56.5 (mm)
*

UP-1202-3

110 / 220VAC
85-265VAC / 30Hz-70Hz
12VDC
Option
Yes
1000 mA
141.5*86.5*57.5 (mm)
*

UP-2402-2

110 / 220VAC
85-265VAC / 30Hz-70Hz
24VDC
Option
Yes
1000 mA
155*115*54 (mm)
*

UP-2402-4

110 / 220VAC
85-265VAC / 30Hz-70H
24VDC
Standard
Yes
1000 mA
162*105*100 (mm)
*

PS-2203-1

110 / 220VAC
110-120VAC / 200-240VAC / 50Hz-60Hz
24VDC
-
-
-
172.5*97*41 (mm)
*

PS-2209-1

110VAC / 220VAC
56Hz-60Hz
24VDC
-
-
-
74.5*50.5*28 (mm)
*

PS-4001-1

400VAC
50Hz~60Hz
24VDC
-
-
-
329*100*70 (mm)
